Request Code | Volume / Quantity | Currency |
|---|---|---|
R20210534 | 1 / ct(undefined) | USD |
Submission deadline | Destination Location | Preferred Incoterm |
|---|---|---|
Jan 23, 2021 (Closed) | Iraq | FCA |
Payment Term | Status | Type |
|---|---|---|
- | Active | Public |
Description | ||
|---|---|---|
FCA or EXW Middle East. Iraq is preferred. ELECTRICAL HEATER FOR CIP TANK WITH FLANGE. REFERENCE MANUFACTORY: SANDVIK SERIAL NUMBER KG 121102-1. FABRICATION TO BE PERFORMED AS PER DATA SHEET 8015-0151-LUEN-22-335-EL-DS-00002. COMPREHENSIVE INFORMATION FOR HEATER FABRICATION IS INDICATED AT THE DATE SHEET. SPECIFICATION OF HEATER: EL. POWER 22KW. SUPPLY SYSTEM: 400V. 3PH. 3 WIRE. TOTAL NUMBER OF HEAT ELEMENTS: 10 (9 ACTIVE + 1 SPARE). HEATING ELEMENT RATING 2444W/400V. T.BOX CERTIFICATION/IP RATING : EX D IIA, IIB, T3/IP65. SHEATH TEMPERATURE: 90C. MECHANICAL DESIGN -HEATER MEDIUM : AOH+HCL+NAOCL. -HEATER BUNDLE ASSEMBLY PARTS: -HEATER FLANGE 1EA. (HASTELLOY C276(UNS N10276)) -HEATING ELEMENTS 9+1EA. (HASTELLOY C276, (UNS N10276)) -BAFFLE PLATE 3EA. (SS316) -TIE ROD 4EA. (SS316) -TIE ROD SLEEVE-1 -04EA. (SS316) -TIE ROD SLEEVE-2 -08EA. (SS316) -TIE ROD LOCK NUTS WITH WASHERS 12+08. (SA 194 GR.8). -RTD FOR SKIN-01EA. (SS316). - RTD FOR HEATER FLANGE -01EA. (SS 316). -LIFTING EYE BOLT -01EA. (SA 105/SA 36). -SECOND FLANGE -01EA. (SA 516 GR.70). -SECOND FLANGE SUPPORT ROD -04EA. (SA36). -SUPPORT ROD BOSS -04EA. (SA 36). -THERMOSTAT POCKET -01EA. (SS 304). -RTD MOUNDING STU AND NUT 02 SET. MS/CROME PLATED. |
